2.67G SFP STM-16 Industrial 80 km, λ1550 nm, DDM, LC-Duplex, Singlemode
- 1550 nm
- 80 km
- 2.67 G
- Industrial
- 100M ETH
- 1G ETH
- 1G FC
- 2G FC
- STM-1
- STM-16
- STM-4
-
Alternatives
-
Matching Products
Just go to cart and click CREATE QUOTE.
-
Alternatives
-
Matching Products
Specification
| Form Factor | SFP |
|---|---|
| Connector / Polish | LC-Duplex PC |
| Interface | Singlemode |
| Compliance Code | STM-16 |
| Operating Temperature | Industrial |
| Modulation | NRZ |
| Distance | 80 km |
| Temperature Range | -40°C - 85°C |
| Bandwidth | 125 Mbit/s - 2.67 Gbit/s |
| Digital Diagnostic Management (DDM) | Yes, internally calibrated |
|---|---|
| Power Consumption | 1 W |
| CDR | none |
| SGMII | No |
| Inbuilt FEC | No |
| Powerbudget (dB) | 26 dB |
| Transmit min/max per lane | -2 dBm / 3 dBm |
| Receiver min/max per lane | -28 dBm / -9 dBm (overload) @2G |
| Wavelength TX (Typical) | 1550 nm |
| Wavelength TX (Range) | 1500 - 1600 nm |
|---|---|
| Wavelength RX (Typical) | 1550 nm |
| Wavelength RX (Range) | 1260 - 1600 nm |
| Laser | DFB |
| Receiver Type | APD |
| Modulation | NRZ @2G |
| Transmit and Dispersion Penalty | 1 dB |
| Extinction Ratio | 8.2 dB |
| Supported Protocols | 1G Fibre Channel, 2G Fibre Channel, Fast Ethernet, Gigabit Ethernet, STM-1, STM-16, STM-4 |
Transceiver Configuration with FLEXBOX
It's that easy to use- Download and start our FLEXOPTIX App
- Connect your FLEXBOX via USB
- Insert a Universal Transceiver
- Choose vendor and compatibility
- Press play
- Configuration only takes a few seconds
- Use the transceiver in your device. That's it!
- Need it for another device? - Re-configure it again and again
Compatibility
All trademarks, registered companies & references cited are the sole property of their respective company and are used solely to assist in the identification of products.
- MSA Standard compatible
- ADTRAN 1184560P5 compatible
- Ciena (ex. Nortel) NTTP05FD compatible
- Cisco Systems ONS-SI-2G-L2 compatible
- Cisco Systems SFP-OC48-LR2 compatible
- Cyan 280-0012-00 compatible
- Cyan SDH compatible
- FiberPlex SFP-SC48XC-5555-F compatible
- Huawei eSFP-1550nm-L-16.2 compatible
- Infinera (ex. Transmode) TRX100054 compatible
- Infinera TOM-2.5GMR-LR2 compatible
- Juniper SFP-1OC48-LR compatible
- Marconi SU68AD compatible
- MRV SFP-MR27D-LR2-R compatible
- Net Insight NPA0022-VL21 compatible
- Nokia (ex. Alcatel-Lucent) 1AB196370009 compatible
- Nokia (ex. Alcatel-Lucent) 1AB376370004 compatible
- Nokia Siemens Networks V50017-U342-K500 compatible
