1G SFP SX 2 km, λ1310 nm, DDM, LC-Duplex, Multimode
- 1310 nm
- 2 km
- 1.25 G
- 1G ETH
- 1G FC
-
Alternativen
-
Passende Produkte
Unsere Auftragsbestätigung wird das endgültige Versanddatum enthalten.
-
~03.01.2024+81 Stk
Geh einfach zum Warenkorb und klicke auf Angebot erstellen.
-
Alternativen
-
Passende Produkte
Spezifikation
Form Factor | SFP |
---|---|
Connector / Polish | LC-Duplex PC |
Interface | Multimode |
Type | SX |
Distance | 2 km |
Temperature Range | 0°C - 70°C |
Bandwidth | 1 Gbit/s - 1.25 Gbit/s |
Digital Diagnostic Management (DDM) | Yes, internally calibrated |
Power Consumption | 1 W |
CDR | none |
---|---|
SGMII | No |
Inbuilt FEC | No |
Powerbudget (dB) | 9 dB |
Transmit min/max per lane | -9 dBm / -3 dBm |
Receiver min/max per lane | -18 dBm / -3 dBm (overload) |
Wavelength TX (Typical) | 1310 nm |
Wavelength TX (Range) | 1260 - 1360 nm |
Wavelength RX (Typical) | 1310 nm |
Wavelength RX (Range) | 1260 - 1600 nm |
---|---|
Laser | FP |
Receiver Type | PIN |
Modulation | NRZ |
Transmit and Dispersion Penalty | 1 dB |
Extinction Ratio | 9 dB |
Supported Protocols | 1G Fibre Channel, Gigabit Ethernet |
TRANSCEIVER KONFIGURATION MIT DER FLEXBOX
SO EINFACH GEHT'S!- Lade unsere App herunter und starte sie: FLEXOPTIX App
- Connect your FLEXBOX via USB
- Stecke einen Universal Transceiver ein
- Suche dir einfach Hersteller und Kompatibilität aus
- Drücke Play
- Die Konfiguration dauert nur ein paar Sekunden
- Benutze den Transceiver in deinem Gerät. Das war's!
- Du brauchst ihn für ein anderes Gerät? - Rekonfiguriere ihn einfach immer wieder
Kompatibiltät
Alle zitierten Marken, eingetragenen Unternehmen und Referenzen sind das alleinige Eigentum der jeweiligen Unternehmen und werden ausschließlich zur Identifizierung der Produkte verwendet.
- MSA Standard kompatibel
- ADVA 0061705824 kompatibel
- Advantech B+B SmartWorx BB-808-38206 kompatibel
- Advantech SFP-GSX/LC-AE kompatibel
- Alcatel-Lucent Ent. SFP-GIG-EXTND kompatibel
- Allied Telesis AT-SPEX kompatibel
- Aruba Networks(ex. HP Network) J4858C kompatibel
- barox AC-SFP-SXOM3-E kompatibel
- Blackbox LFP412 kompatibel
- Brocade / Ruckus E1MG-SX2-OM kompatibel
- Brocade E1MG-SX2-OM kompatibel
- Cisco Systems GLC-SX-MMD kompatibel
- Cisco Systems SFP-GE-S kompatibel
- ComNet SFP-46 kompatibel
- CTC Union ISFP-M7002-31-D kompatibel
- D-LINK DEM-312GT2 kompatibel
- Dell (ex. Force10) GP-SFP2-1E kompatibel
- Edge Core ET4202-SX kompatibel
- Extreme (ex. Enterasys) MGBIC-LC03 kompatibel
- Extreme 10051H kompatibel
- FiberPlex SFP-MC24XC-3131-2 kompatibel
- FibroLAN SF1G-S2 kompatibel
- Fortinet FG-TRAN-SX kompatibel
- Hirschmann M-SFP-MX/LC kompatibel
- Intel SFP LX kompatibel
- Juniper SFP-1GE-SX kompatibel
- Korenix SFPGSX2D kompatibel
- KTI Networks SFP-GLM-A-1310 kompatibel
- LAWO 981/60-80 kompatibel
- MikroTik S-85DLC05D kompatibel
- Moxa SFP-1GLSXLC kompatibel
- MRV SFP-GD-MX kompatibel
- Netgear AGM732F kompatibel
- OpenGear 569024 kompatibel
- Perle PSFP-1000D-M2LC2 kompatibel
- Planet MGB-SX2 kompatibel
- Riedel 1090003 kompatibel
- Siemens 6GK5992-1AG00-8AA0 kompatibel
- TP-LINK TL-SM311LM kompatibel
- Transition Networks TN-SFP-ESX kompatibel
- Ubiquiti Networks UF-MM-1G kompatibel
- Volktek GBM-104-2 kompatibel
- Westermo 1100-0547 kompatibel
- Zyxel SFP-SX kompatibel
