Standard Transceiver (SX, LX, ...)
| S. Typ |
13 Wellenlänge |
12. Datenrate |
10 Reichweite |
D Monitoring |
|---|---|---|---|---|
| S = SFP P = SFP+ T = Kupfer X = XFP G = GBIC 2 = X2 K = Xenpak Q = QSFP |
85 = 850nm 13 = 1310nm 15 = 1550nm Bxx = BiDi C = Kupfer |
12 = 1.25G 24 = 2.5G 26 = 2.67G 48 = 4.25G 80 = 8.5G 96 = 8.5-11.3G 40G = 40G |
02 = < 2km 10 = 10km 40 = 40km 80 = 80km A = 100km B = 120km C = 160km |
D = DDM/DOM (.D nur für unter 10G) |
| P. Typ |
16 Wellenlänge |
12. Datenrate |
19. Power Budget |
z Code |
D Monitoring |
|---|---|---|---|---|---|
| S = SFP P = SFP+ X = XFP G = GBIC Q = QSFP+ |
16 = CWDM | 12 = 1.25G 24 = 2.5G 26 = 2.67G 48 = 4.25G 80 = 8.5G 96 = 8.5-11.3G 40G = 40G |
XX in dB für QSFP = 10 |
z.B. K für 1470nm |
D = DDM |
| (.zD nicht für QSFP) | |||||
| P. Typ |
16 Wellenlänge |
96 Datenrate |
23 Power Budget |
yy DWDM Channel |
|---|---|---|---|---|
| S = SFP P = SFP+ X = XFP G = GBIC |
16 = DWDM | 12 = 1.25G 24 = 2.5G 26 = 2.67G 48 = 4.25G 80 = 8.5G 96 = 8.5-11.3G |
XX in dB | z.B. 53 für ITU- Channel 53 (100GHz grid) DWDM ITU-channel-Liste |
| K. Typ |
PCT |
|---|---|
| K = Xenpak 2 = X2 |
