155M SFP STM-1 BiDi 40 km, ᵀˣ1550 / ᴿˣ1310 nm, DDM, LC-Simplex, Singlemode
- 1550 nm
- 40 km
- 155 M
- BiDi
- 100M ETH
- STM-1
-
Alternatives
-
Matching Products
Just go to cart and click CREATE QUOTE.
-
Alternatives
-
Matching Products
Specification
| Form Factor | SFP |
|---|---|
| Connector / Polish | LC-Simplex UPC |
| Interface | Singlemode BiDi |
| Compliance Code | BiDi EX |
| Operating Temperature | Standard |
| Modulation | NRZ |
| Distance | 40 km |
| Temperature Range | 0°C - 70°C |
| Bandwidth | 125 Mbit/s - 155 Mbit/s |
| Digital Diagnostic Management (DDM) | Yes, internally calibrated |
|---|---|
| Power Consumption | 1 W |
| CDR | none |
| SGMII | No |
| Inbuilt FEC | No |
| Powerbudget (dB) | 28 dB |
| Transmit min/max per lane | -5 dBm / 0 dBm |
| Receiver min/max per lane | -33 dBm / -10 dBm (overload) @100M - 800M |
| Wavelength TX (Typical) | 1550 nm |
| Wavelength TX (Range) | 1500 - 1580 nm |
|---|---|
| Wavelength RX (Typical) | 1310 nm |
| Wavelength RX (Range) | 1260 - 1360 nm |
| Laser | DFB |
| Receiver Type | PIN |
| Modulation | NRZ @100M - 800M |
| Extinction Ratio | 8.2 dB |
| Supported Protocols | Fast Ethernet, STM-1 |
Transceiver Configuration with FLEXBOX
It's that easy to use- Download and start our FLEXOPTIX App
- Connect your FLEXBOX via USB
- Insert a Universal Transceiver
- Choose vendor and compatibility
- Press play
- Configuration only takes a few seconds
- Use the transceiver in your device. That's it!
- Need it for another device? - Re-configure it again and again
Compatibility
All trademarks, registered companies & references cited are the sole property of their respective company and are used solely to assist in the identification of products.
- MSA Standard compatible
- A10networks # 11774 compatible
- ADVA # 11775 compatible
- Allied Telesis # 11777 compatible
- Aruba Networks(ex. HP Network) # 11772 compatible
- Avaya (ex. Nortel) # 11779 compatible
- Brocade # 11780 compatible
- Check Point # 11782 compatible
- Ciena (ex. Nortel) # 11783 compatible
- Ciena XCVR-A40S55 compatible
- Cisco Systems ONS-SI-155-L1 compatible
- D-LINK # 11785 compatible
- Dell # 11784 compatible
- Dell (ex. Force10) # 11792 compatible
- Extreme # 11788 compatible
- Extreme (ex. Enterasys) # 11787 compatible
- F5 Networks # 11789 compatible
- FibroLAN # 11790 compatible
- Fluke Networks # 11791 compatible
- Fortinet # 11793 compatible
- Fujitsu # 11794 compatible
- H3C (ex. 3COM) # 11773 compatible
- Hirschmann # 11795 compatible
- HP H3C # 11796 compatible
- Huawei eSFP-1550/1310-L1.1-BIDI compatible
- Infinera (ex. Transmode) # 11814 compatible
- Intel # 11799 compatible
- Juniper # 11800 compatible
- Juniper (ex BTI Systems) # 11781 compatible
- Korenix SFP100SM40B15D compatible
- KTI Networks # 11801 compatible
- LANCOM # 11802 compatible
- Lenovo (ex. Blade Network) # 11798 compatible
- LevelOne SFP-7431 compatible
- Marconi SU66AB compatible
- MikroTik # 11804 compatible
- Moxa # 11805 compatible
- MRV SFP-FD-BD35 compatible
- Netgear # 11807 compatible
- Nokia (ex. Alcatel-Lucent) # 11776 compatible
- Nokia Siemens Networks V50017-U413-K500 compatible
- Palo Alto Networks # 11810 compatible
- Perle PSFP-100D-S1LC40D compatible
- RAD SFP-18B compatible
- Radware # 11811 compatible
- Ribbon (ex. ECI) OTR1_L5BD compatible
- Riedel 1090084 compatible
- TP-LINK # 11812 compatible
- Transition Networks TN-SFP-OC3SB42 compatible
- Waystream (ex. Packetfront) # 11809 compatible
- Westermo 1100-0155 compatible
