100M SFP BiDi EX 40 km, ᵀˣ1310 / ᴿˣ1550 nm, DDM, LC-Simplex, Singlemode

Universal SFP BiDi Transceiver
Use FLEXBOX to configure to almost any vendor
Double your bandwith by using only one fiber for transmit and receive
For 100M - 800MBASE-EX Ethernet links
Supported Data Rates: 125 Mbit/s - 155 Mbit/s
Up to 40 km via Singlemode OS2
LC-Simplex Connector
Digital Diagnocstic Monitoring (DDM)
Specs
  • 1310 nm
  • 40 km
  • 155 M
  • BiDi
Protocols
  • 100M ETH
  • STM-1
Request compatibility
Part number
S.B1303.40.DL
Availability
4-6 weeks after ordering
You can create a quote from your cart.
Just go to cart and click CREATE QUOTE.

  • Matching Products

LWL Fibre Cleaner LC / Belt clip edition
LWL Fibre Cleaner LC / Belt clip edition
14 pcs in stock 92.07 EUR

Specification

Form Factor SFP
Connector / Polish LC-Simplex UPC
Interface Singlemode BiDi
Type BiDi EX
Distance 40 km
Temperature Range 0°C - 70°C
Bandwidth 125 Mbit/s - 155 Mbit/s
Digital Diagnostic Management (DDM) Yes, internally calibrated
Power Consumption 1 W
CDR none
SGMII No
Inbuilt FEC No
Powerbudget (dB) 28 dB
Transmit min/max per lane -5 dBm / 0 dBm
Receiver min/max per lane -33 dBm / -10 dBm (overload)
Wavelength TX (Typical) 1310 nm
Wavelength TX (Range) 1260 - 1360 nm
Wavelength RX (Typical) 1550 nm
Wavelength RX (Range) 1500 - 1580 nm
Laser FP
Receiver Type PIN
Modulation NRZ
Extinction Ratio 8.2 dB
Supported Protocols Fast Ethernet, STM-1

Transceiver Configuration with FLEXBOX

It's that easy to use
Insert Transceiver into FLEXBOX
1. Insert Into FLEXBOX
Select and Configure
2. Select And Configure
  • Choose vendor and compatibility
  • Press play
  • Configuration only takes a few seconds
Use with Device
3. Use With Device
  • Use the transceiver in your device. That's it!
  • Need it for another device? - Re-configure it again and again
How to get your free FLEXBOX

Compatibility

All trademarks, registered companies & references cited are the sole property of their respective company and are used solely to assist in the identification of products.

  • MSA Standard compatible
  • A10networks # 11730 compatible
  • ADVA # 11731 compatible
  • Allied Telesis # 11733 compatible
  • Aruba Networks(ex. HP Network) # 11728 compatible
  • Avaya (ex. Nortel) # 11735 compatible
  • Brocade # 11736 compatible
  • Check Point # 11738 compatible
  • Ciena (ex. Nortel) # 11739 compatible
  • Ciena XCVR-A40S31 compatible
  • Cisco Systems ONS-SI-155-L1 compatible
  • D-LINK # 11741 compatible
  • Dell # 11740 compatible
  • Dell (ex. Force10) # 11748 compatible
  • Extreme # 11744 compatible
  • Extreme (ex. Enterasys) # 11743 compatible
  • F5 Networks # 11745 compatible
  • FibroLAN # 11746 compatible
  • Fluke Networks # 11747 compatible
  • Fortinet # 11749 compatible
  • Fujitsu # 11750 compatible
  • H3C (ex. 3COM) # 11729 compatible
  • Hirschmann # 11751 compatible
  • HP H3C # 11752 compatible
  • Huawei eSFP-1310/1550-L1.1-BIDI compatible
  • Infinera (ex. Transmode) # 11770 compatible
  • Intel # 11755 compatible
  • Juniper (ex BTI Systems) # 11737 compatible
  • Juniper EX-SFP-1FE-LX40K compatible
  • Korenix SFP100SM40B13D compatible
  • KTI Networks # 11757 compatible
  • LANCOM # 11758 compatible
  • Lenovo (ex. Blade Network) # 11754 compatible
  • LevelOne SFP-7421 compatible
  • Marconi SU66AB compatible
  • MikroTik # 11760 compatible
  • Moxa # 11761 compatible
  • MRV SFP-FD-BD53 compatible
  • Netgear # 11763 compatible
  • Nokia (ex. Alcatel-Lucent) # 11732 compatible
  • Nokia Siemens Networks V50017-U403-K500 compatible
  • Palo Alto Networks # 11766 compatible
  • Perle PSFP-100D-S1LC40U compatible
  • RAD SFP-18A compatible
  • Radware # 11767 compatible
  • Ribbon (ex. ECI) OTR1_L3BD compatible
  • Riedel 1090083 compatible
  • TP-LINK # 11768 compatible
  • Transition Networks TN-SFP-OC3SB41 compatible
  • Waystream (ex. Packetfront) # 11765 compatible
  • Westermo 1100-0154 compatible
