1G SFP BiDi LX 3 km, ᵀˣ1310 / ᴿˣ1550 nm, DDM, LC-Simplex, Singlemode

- 1310 nm
- 3 km
- 1.25 G
- BiDi
- 100M ETH
- 1G ETH
- 1G FC
-
Alternatives
-
Matching Products
Just go to cart and click CREATE QUOTE.
-
Alternatives
-
Matching Products
Specification
Form Factor | SFP |
---|---|
Connector / Polish | LC-Simplex UPC |
Interface | Singlemode BiDi |
Compliance Code | BiDi LX |
Operating Temperature | Standard |
Modulation | NRZ |
Distance | 3 km |
Temperature Range | 0°C - 70°C |
Bandwidth | 125 Mbit/s - 1.25 Gbit/s |
Digital Diagnostic Management (DDM) | Yes, internally calibrated |
---|---|
Power Consumption | 1 W |
CDR | none |
SGMII | No |
Inbuilt FEC | No |
Powerbudget (dB) | 8 dB |
Transmit min/max per lane | -14 dBm / -8 dBm |
Receiver min/max per lane | -22 dBm / -3 dBm (overload) @1G |
Wavelength TX (Typical) | 1310 nm |
Wavelength TX (Range) | 1260 - 1360 nm |
---|---|
Wavelength RX (Typical) | 1550 nm |
Wavelength RX (Range) | 1480 - 1580 nm |
Laser | FP |
Receiver Type | PIN |
Modulation | NRZ @1G |
Extinction Ratio | 6 dB |
Supported Protocols | 1G Fibre Channel, Fast Ethernet, Gigabit Ethernet |
Transceiver Configuration with FLEXBOX
It's that easy to use- Download and start our FLEXOPTIX App
- Connect your FLEXBOX via USB
- Insert a Universal Transceiver
- Choose vendor and compatibility
- Press play
- Configuration only takes a few seconds
- Use the transceiver in your device. That's it!
- Need it for another device? - Re-configure it again and again
Compatibility
All trademarks, registered companies & references cited are the sole property of their respective company and are used solely to assist in the identification of products.
- MSA Standard compatible
- Cisco Systems GLC-BX-U compatible
- Fortinet FG-TRAN-LX compatible
- Juniper EX-SFP-GE10KT13R15 compatible
- MikroTik S-35LC20D compatible
- Netgear AGM732F compatible
- Siemens SFP992-1LD. compatible
- TP-LINK TL-SM311LS compatible
- Ubiquiti Networks UF-SM-1G-S BU compatible
