1G SFP BiDi ZX+ 120 km, ᵀˣ1490 / ᴿˣ1590 nm, DDM, LC-Simplex, Singlemode
- 1490 nm
- 120 km
- 1.25 G
- BiDi
- 100M ETH
- 1G ETH
- 1G FC
Just go to cart and click CREATE QUOTE.
Specification
| Form Factor | SFP |
|---|---|
| Connector / Polish | LC-Simplex UPC |
| Interface | Singlemode BiDi |
| Compliance Code | BiDi ZX+ |
| Operating Temperature | Standard |
| Modulation | NRZ |
| Distance | 120 km |
| Temperature Range | 0°C - 70°C |
| Bandwidth | 125 Mbit/s - 1.25 Gbit/s |
| Digital Diagnostic Management (DDM) | Yes, internally calibrated |
|---|---|
| Power Consumption | 1 W |
| CDR | none |
| SGMII | No |
| Inbuilt FEC | No |
| Powerbudget (dB) | 33 dB |
| Transmit min/max per lane | 0 dBm / 5 dBm |
| Receiver min/max per lane | -33 dBm / -8 dBm (overload) @1G |
| Wavelength TX (Typical) | 1490 nm |
| Wavelength TX (Range) | 1483.5 - 1497 nm |
|---|---|
| Wavelength RX (Typical) | 1590 nm |
| Wavelength RX (Range) | 1570 - 1610 nm |
| Laser | DFB |
| Receiver Type | APD |
| Modulation | NRZ @1G |
| Transmit and Dispersion Penalty | 1 dB |
| Extinction Ratio | 9 dB |
| Supported Protocols | 1G Fibre Channel, Fast Ethernet, Gigabit Ethernet |
Transceiver Configuration with FLEXBOX
It's that easy to use- Download and start our FLEXOPTIX App
- Connect your FLEXBOX via USB
- Insert a Universal Transceiver
- Choose vendor and compatibility
- Press play
- Configuration only takes a few seconds
- Use the transceiver in your device. That's it!
- Need it for another device? - Re-configure it again and again
Compatibility
All trademarks, registered companies & references cited are the sole property of their respective company and are used solely to assist in the identification of products.
- MSA Standard compatible
- Cisco Systems GLC-BX80-U-I compatible
- Extreme 10053H compatible
- Ribbon (ex. ECI) OTGBE_L5BD80 compatible
