4G Fibre Channel SFP 380 m, λ850 nm, DDM, LC-Duplex, Multimode
- 850 nm
- 380 m
- 4.25 G
- 1G ETH
- 1G FC
- 2G FC
- 4G FC
Just go to cart and click CREATE QUOTE.
Specification
| Form Factor | SFP |
|---|---|
| Connector / Polish | LC-Duplex PC |
| Interface | Multimode |
| Compliance Code | 4G FC SW |
| Operating Temperature | Standard |
| Modulation | NRZ |
| Distance | 380 m |
| Temperature Range | 0°C - 70°C |
| Bandwidth | 1.05 Gbit/s - 4.25 Gbit/s |
| Digital Diagnostic Management (DDM) | Yes, internally calibrated |
|---|---|
| Power Consumption | 1 W |
| CDR | none |
| SGMII | No |
| Inbuilt FEC | No |
| Powerbudget (dB) | 6 dB |
| Transmit min/max per lane | -9 dBm / 0 dBm |
| Receiver min/max per lane | -15 dBm / -3 dBm (overload) @4G |
| Wavelength TX (Typical) | 850 nm |
| Wavelength TX (Range) | 830 - 860 nm |
|---|---|
| Wavelength RX (Typical) | 850 nm |
| Wavelength RX (Range) | 760 - 860 nm |
| Laser | VCSEL |
| Receiver Type | PIN |
| Modulation | NRZ @4G |
| Extinction Ratio | 5 dB |
| Supported Protocols | 1G Fibre Channel, 2G Fibre Channel, 4G Fibre Channel, Gigabit Ethernet |
Transceiver Configuration with FLEXBOX
It's that easy to use- Download and start our FLEXOPTIX App
- Connect your FLEXBOX via USB
- Insert a Universal Transceiver
- Choose vendor and compatibility
- Press play
- Configuration only takes a few seconds
- Use the transceiver in your device. That's it!
- Need it for another device? - Re-configure it again and again
Compatibility
All trademarks, registered companies & references cited are the sole property of their respective company and are used solely to assist in the identification of products.
- MSA Standard compatible
- Brocade 57-1000013-01 compatible
- Ciena (ex. Nortel) NTTP11AFE6 compatible
- Cisco Systems DS-SFP-FC4G-SW compatible
- Cisco Systems ONS-SE-4G-MM compatible
- Cyan 280-0286-00 compatible
- HP Storage (B-Series) A7446B compatible
- Huawei 34060365 compatible
- Infinera (ex. Transmode) TRX100047 compatible
- Lenovo (ex. IBM) 39R6475 compatible
- MRV SFP-TGD-SX compatible
- NetApp X6539-R6 compatible
- Nokia (ex. Alcatel-Lucent) 1AB379640003 compatible
- Packetlight SL1 compatible
- Packetlight SL2 compatible
- Perle PSFP-4GD-M2LC05 compatible
- QLogic SFP4-SW-1PK compatible
- Ribbon (ex. ECI) OTFC4_MM compatible
- Riedel 1990001 compatible
- Transition Networks TN-SFP-FC4XM compatible
