1G SFP Wideband BiDi LX 10 km, ᵀˣ1310 / ᴿˣ1470-1600 nm, DDM, LC-Simplex, Singlemode
SFP
BiDi LX
Universal SFP Wideband BiDi Transceiver
Use FLEXBOX to configure to almost any vendor
Double your bandwith by using only one fiber for transmit and receive
For 1000BASE-LX Ethernet links
Reduce spare part stock: Wideband receiver for 1470 nm - 1600 nm
Supported Data Rates: 125 Mbit/s - 1.25 Gbit/s
Up to 10 km via Singlemode OS2
LC-Simplex Connector
Digital Diagnocstic Monitoring (DDM)
Specs
- 1310 nm
- 10 km
- 1.25 G
- Wideband BiDi
Protocols
- 100M ETH
- 1G ETH
- 1G FC
-
Alternatives
-
Matching Products
-
Alternatives
-
Matching Products
Specification
| Form Factor | SFP |
|---|---|
| Connector / Polish | LC-Simplex UPC |
| Interface | Singlemode BiDi |
| Compliance Code | BiDi LX |
| Distance | 10 km |
| Temperature Range | 0°C - 70°C |
| Bandwidth | 125 Mbit/s - 1.25 Gbit/s |
| Digital Diagnostic Management (DDM) | Yes, internally calibrated |
| Power Consumption | 1 W |
|---|---|
| CDR | none |
| SGMII | No |
| Inbuilt FEC | No |
| Powerbudget (dB) | 12.5 dB |
| Transmit min/max per lane | -9.5 dBm / -3 dBm |
| Receiver min/max per lane | -22 dBm / -3 dBm (overload) @1G |
| Wavelength TX (Typical) | 1310 nm |
| Wavelength TX (Range) | 1260 - 1360 nm |
|---|---|
| Wavelength RX (Typical) | 1550 nm |
| Wavelength RX (Range) | 1470 - 1600 nm |
| Laser | FP |
| Receiver Type | PIN |
| Modulation | NRZ @1G |
| Extinction Ratio | 9 dB |
| Supported Protocols | 1G Fibre Channel, Fast Ethernet, Gigabit Ethernet |
Transceiver Configuration with FLEXBOX
It's that easy to use
1. Insert Into FLEXBOX
- Download and start our FLEXOPTIX App
- Connect your FLEXBOX via USB
- Insert a Universal Transceiver
2. Select And Configure
- Choose vendor and compatibility
- Press play
- Configuration only takes a few seconds
3. Use With Device
- Use the transceiver in your device. That's it!
- Need it for another device? - Re-configure it again and again
Compatibility
All trademarks, registered companies & references cited are the sole property of their respective company and are used solely to assist in the identification of products.
- MSA Standard compatible
- ADTRAN 1442110G2 compatible
- ADVA 0061003012 compatible
- Alcatel-Lucent Ent. SFP-GIG-BX-U compatible
- Allied Telesis AT-SPBD10-13 compatible
- Arista 3rd_Party SFP-1G-LX compatible
- Arista SFP-1G-LX compatible
- Aruba Networks(ex. HP Network) J4859C compatible
- AudioCodes SFP BX-U compatible
- Avaya (ex. Nortel) AA1419069-E6 compatible
- AVM Fritz!SFP AON compatible
- Brocade / Ruckus E1MG-BXU compatible
- Calix 100-01666 compatible
- Ciena (ex. Nortel) NTTP58BD compatible
- Ciena XCVR-B10U31 compatible
- Cisco (ex. Meraki) MA-SFP-1GB-LX10 compatible
- Cisco Systems (ex. Linksys) MGBBX1 compatible
- Cisco Systems GLC-BX-U compatible
- Coriant (ex. Tellabs) 81.S1GBEBX1133S compatible
- D-LINK DEM-330R compatible
- Dell 407-10588 compatible
- Dell 407-BBOO compatible
- Delock 86189 compatible
- Edge Core ET4204-BX10 compatible
- Extreme (ex. Enterasys) MGBIC-BX10-U compatible
- Extreme 10057 compatible
- FibroLAN SF1G-SF13 compatible
- Fluke Networks SFP-1000LX compatible
- Fortinet FG-TRAN-LX compatible
- HP H3C JD098B compatible
- Huawei SFP-GE-LX-SM1310-BIDI compatible
- Infinera (ex. Transmode) TRX100080 compatible
- Intel SFP BIDI 1310 compatible
- Juniper (ex BTI Systems) BP3AM5MB compatible
- Juniper EX-SFP-GE10KT13R15 compatible
- Juniper SFP-GE10KT13R15 compatible
- Korenix SFPGLX10B13D compatible
- LANCOM SFP-LX-LC1 compatible
- Lenovo (ex. IBM) 26R0808 compatible
- LevelOne SFP-9221 compatible
- MikroTik S-35LC20D compatible
- Moxa SFP-1G10ALC compatible
- Netgear AGM732F compatible
- Nexans 88646073 compatible
- Nokia (ex. Alcatel-Lucent) 1AB350870001 compatible
- Nokia (ex. Alcatel-Lucent) 3FE25772AA compatible
- Nokia Siemens Networks V50017-U402-K500 compatible
- Nokia-Siemens (ex. Atrica) AT10076-0D-R compatible
- Nvidia (ex. Mellanox) MC3208011-SX compatible
- Palo Alto Networks PAN-SFP-LX compatible
- Planet MGB-LA10 compatible
- RAD SFP-28AD compatible
- SonicWALL 01-SSC-9790 compatible
- Sophos ASG0000LX compatible
- Sophos SGIZTCHF2 compatible
- Supermicro AOC-E10GSFPLR compatible
- TP-LINK TL-SM321B compatible
- Transition Networks TN-SFP-LXB11 compatible
- TRENDnet TEG-MGBS10D3 compatible
- Turris Omnia SFP BIDI 1310 compatible
- Ubiquiti Networks SFP-BIDI-1310-10 compatible
- Westermo 1100-0558 compatible
- Zyxel SFP-BX1310-10 compatible
Your vendor / compatibility is missing?
