25G SFP28 AOC Multimode Fiber, 1 - 100 m

Universal Active Optical Cable (AOC), 1 - 100 m
Use FLEXBOX to configure to almost any vendor
SFP28 to SFP28
Supported Datarate 25.78 Gbit/s
Modules are permanently attached to each end
Low power consumption < 1.5 W (less than 0.75 W per terminal)
Easy cable routing thanks to small diameter (Ø 2 mm) and bend radius
Connect different host systems by configuring each side individually
Specs
  • Fiber
  • 1m - 100m
  • 25.78 G
  • Active
Protocols
  • 25G ETH
Request compatibility
Part number
P.A8525G.z

Add Product to Quote

If you add products discounts in this quote won't be valid anymore!
Cancel OK
You can create a quote from your cart.
Just go to cart and click CREATE QUOTE.

  • Alternatives

2x
25G SFP28 SR with dual CDR 100 m, λ850 nm, LC-Duplex, Multimode
25G SFP28 SR with dual CDR | 100 m, λ850 nm, LC-Duplex, Multimode
25175 pcs in stock As low as 54.33 EUR
+
LC-Duplex to LC-Duplex Multimode OM3 cable 50/125 µm, aqua, 0.5 m - 100 m
LC-Duplex to LC-Duplex Multimode OM3 cable | 50/125 &#181;m, aqua, 0.5 m - 100 m
As low as 9.63 EUR

Specification

Compliance Code AOC
Form Factor SFP28 to SFP28
Interface Active Optical Cable
Length 100 m
Temperature Range 0°C - 70°C
Bandwidth 25.78 Gbit/s
Digital Diagnostic Management (DDM) implemented
Power Consumption 1.5 W (0.75 W + 0.75 W)
CDR none
Modulation NRZ
Supported Protocols 25G Ethernet

Transceiver Configuration with FLEXBOX

It's that easy to use
Insert Transceiver into FLEXBOX
1. Insert Into FLEXBOX
Select and Configure
2. Select And Configure
  • Choose vendor and compatibility
  • Press play
  • Configuration only takes a few seconds
Use with Device
3. Use With Device
  • Use the transceiver in your device. That's it!
  • Need it for another device? - Re-configure it again and again
How to get your free FLEXBOX

Compatibility

All trademarks, registered companies & references cited are the sole property of their respective company and are used solely to assist in the identification of products.

  • MSA Standard compatible
  • Cisco Systems SFP-25G-SR-S compatible
  • Fortinet FN-TRAN-SFP28-SR compatible
  • Juniper JNP-25G-AOC-30M compatible
  • Nvidia (ex. Mellanox) MMA2P00-AS compatible
  • Palo Alto Networks PAN-SFP28-25GBASE-SR compatible
  • QLogic SFP28-25G-SR compatible
