CFP2 to QSFP28 adapter converter module, Multimode, Singlemode

Universal'>Universal Adapter Module for CFP2
Use FLEXBOX to configure to almost any vendor
Use QSFP28 in CFP2 port of your device
Transceivers are not included and sold separately
Lower Power Consumption than using an equivalent CFP2
Supported Data Rates: 103 Gbit/s - 112 Gbit/s
Specs
  • Adapter
  • 112 G
  • QSFP28
Protocols
  • 100G ETH
  • OTU4
Part number
C2.1HG.QCT
In stock
5 pcs
Back In Stock
Estimated arrival of additional items.
Our order confirmation will provide the final shipping date.
  • ~Oct 20, 2023
    +4 pcs
You can create a quote from your cart.
Just go to cart and click CREATE QUOTE.

Specification

Form Factor CFP2
Temperature Range 0°C - 70°C
Digital Diagnostic Management (DDM) depends on transceiver
CDR TX and RX
Inbuilt FEC No
Supported Protocols 100G Ethernet, OTU4
Power Consumption 1.8 W
Type ADAPTER
Interface SFI

Transceiver Configuration with FLEXBOX

It's that easy to use
Insert Transceiver into FLEXBOX
1. Insert Into FLEXBOX
Select and Configure
2. Select And Configure
  • Choose vendor and compatibility
  • Press play
  • Configuration only takes a few seconds
Use with Device
3. Use With Device
  • Use the transceiver in your device. That's it!
  • Need it for another device? - Re-configure it again and again

Compatibility

All trademarks, registered companies & references cited are the sole property of their respective company and are used solely to assist in the identification of products.

  • MSA Standard (LR4) compatible
  • MSA Standard (SR10) compatible
  • MSA Standard (SR4) compatible
  • MSA Standard (ZR4) compatible
  • Brocade 100G-CFP2-LR4-10KM compatible
  • HP H3C JH289A compatible
  • Huawei OSN010N09 compatible
  • Juniper CFP2-100GBASE-LR4 compatible
  • Nokia (ex. Alcatel-Lucent) 3HE08217AA compatible
  • Nokia (ex. Alcatel-Lucent) 3HE08312AA compatible
  • Nokia (ex. Alcatel-Lucent) 3HE09255AA compatible
  • Ribbon (ex. ECI) OTR100P2_LR4 compatible
  • Ribbon (ex. ECI) OTR100P2_SR10 compatible
Your vendor / compatibility is missing?
